Deye LV 10kW Single Phase Hybrid Inverter - SUN-10K-SG02LP1-AU-AM3

Overview

The Deye 10 kW Single-Phase Low Voltage Hybrid Inverter is designed for modern residential solar energy systems requiring efficient power conversion and seamless battery integration. It converts DC power from solar PV into usable AC electricity while enabling energy storage for improved self-consumption and backup capability.

With dual MPPT inputs, wide PV voltage range, and high battery charge and discharge current, this inverter is well suited to Australian homes looking to future-proof their energy systems with reliable hybrid functionality.

Key Features

Hybrid Solar & Battery Control

• Single-phase hybrid inverter for residential applications
• Rated AC output power: 10 kW
• Supports solar PV, battery storage, and grid interaction

Low-Voltage Battery Compatibility

• Battery voltage range: 40–60 V
• Compatible with 48 V lithium-ion and lead-acid batteries
• Maximum charge / discharge current: 190 A

Optimised Solar Input

• Maximum PV input power: 13.0 kW
• 2 MPPTs for flexible PV array configuration
• MPPT operating voltage range: 125–550 V
• Maximum PV input voltage: 600 V
• Maximum input current per MPPT: 16 A

Reliable Outdoor Performance

• IP65 ingress protection for indoor or outdoor installation
• Operating temperature range: -25°C to +60°C
• Designed for continuous residential operation
