Deye LV 10kW Three Phase Hybrid Inverter - SUN-10K-SG04LP3-AU

Overview

The DEYE Low Voltage Three Phase 10kW Hybrid Inverter (SUN-10K-SG04LP3-AU) is a powerful and versatile energy solution designed for Australian residential and light commercial solar applications. It seamlessly integrates solar generation, battery storage, and grid interaction, supporting both on-grid and off-grid operating modes.

With high PV input capacity, dual MPPT tracking, and advanced battery integration, this inverter enables optimal energy harvesting, efficient self-consumption, and reliable backup power. Its robust construction and intelligent cooling system ensure dependable performance across a wide range of environmental conditions.

Key Features

Solar & Inverter Performance

• Rated output power: 10 kW (three phase)
• 2 MPPT channels for flexible PV system design
• Maximum DC input power: 15,000 W
• Maximum PV input voltage: 800 V
• MPPT voltage range: 200 – 650 V
• Start-up voltage: 160 V

Battery Integration

• Battery voltage range: 40 – 60 V
• Compatible with lithium-ion and lead-acid batteries
• Maximum charging / discharging current: 210 A
• Single battery input

Efficiency & Reliability

• Maximum efficiency: 97.6%
• Euro efficiency: 96.5%
• MPPT efficiency: >99%
• Operating temperature range: -40°C to +60°C (derating above 45°C)
• Ingress protection rating: IP65

Design & Installation

• Cooling system: Intelligent air cooling
• Designed for indoor and outdoor installation
• Suitable for residential and light commercial environments
