DEYE Low Voltage Hybrid Inverter Three Phase 12kW
The DEYE SUN-12K-SG04LP3-AU is a three-phase hybrid inverter designed for residential and light commercial solar applications in Australia. With a rated output of 12kW, it efficiently converts DC power from solar panels into AC power, supporting both on-grid and off-grid configurations.
Specifications
Rated Output Power: 12 kW
Battery Voltage Range: 40–60 V (compatible with lithium-ion and lead-acid batteries)
Max. Charging/Discharging Current: 240 A
Number of Battery Inputs: 1
MPPT Channels: 2
Max. DC Input Power: 18,000 W
Rated DC Input Voltage: 550 V
Start-up Voltage: 160 V
MPPT Voltage Range: 200–650 V
Max. Operating PV Input Voltage: 800 V
Max. Operating PV Input Current: 26 + 13 A
Max. AC Output Active Power: 12,000 W
Max. Efficiency: 97.6%
Euro Efficiency: 96.5%
MPPT Efficiency: >99%
Operating Temperature Range: -40°C to +60°C (derating above 45°C)
Ingress Protection: IP65
Cooling: Intelligent Air Cooling
Warranty: 10 years
Data Sheet:
https://files.dpa.energy/wp-content/uploads/2025/10/datasheet_sun-5-12k-sg04lp3-au_241111_au.pdf
User Manual:
https://files.dpa.energy/wp-content/uploads/2025/10/Mauel-Sheet-5-12l-sg04lp3-au.pdf
