Deye LV 6kW Single Phase Hybrid Inverter - SUN-6K-SG04LP1-AU

Overview

The DEYE 6 kW Single-Phase Low Voltage Hybrid Inverter is designed for residential solar energy systems seeking efficient power conversion and battery-ready flexibility. It seamlessly converts DC power from solar PV into AC electricity for household use while supporting integrated battery storage.

With high conversion efficiency, wide MPPT operating range, and robust environmental protection, this inverter is well suited for Australian homes looking to maximise self-consumption, enable backup power, and future-proof their energy system.

Key Features

Hybrid Solar & Battery Control

• Single-phase hybrid inverter for residential applications
• Supports solar PV, battery storage, and grid interaction
• Rated AC output power: 6,000 W

Low-Voltage Battery Compatibility

• Battery voltage range: 40–60 V
• Maximum charging current: 135 A
• Maximum discharging current: 135 A

Optimised Solar Input

• Maximum DC input power: 12,000 W
• MPPT voltage range: 150–425 V
• Start-up voltage: 125 V
• MPPT efficiency: >99%

High Efficiency & Reliability

• Maximum efficiency: 97.6%
• Euro efficiency: 96.5%
• Designed for continuous residential operation

Rugged Outdoor Design

• IP65 ingress protection for indoor or outdoor installation
• Operating temperature range: -40°C to +60°C
