Deye LV 6kW Three Phase Hybrid Inverter - SUN-6K-SG04LP3-AU
Deye LV 6kW Three Phase Hybrid Inverter - SUN-6K-SG04LP3-AU
Description
Overview
The DEYE Low Voltage Three Phase 6 kW Hybrid Inverter (SUN-6K-SG04LP3-AU) is a robust hybrid inverter designed for residential and light commercial solar installations across Australia. Delivering balanced three-phase output, it efficiently converts DC power from solar PV arrays into usable AC electricity while seamlessly integrating battery storage.
Designed to support both on-grid and off-grid system configurations, this inverter offers flexibility and resilience for modern energy systems. Compatibility with low-voltage battery systems (40–60 V), combined with intelligent thermal management and a durable IP65-rated enclosure, ensures reliable performance in demanding environments.
Key Features
Three-Phase Hybrid Energy Platform
- Three-phase hybrid inverter for balanced power distribution
- Suitable for residential and light commercial solar applications
- Supports on-grid and off-grid operating modes
Battery Compatibility & Performance
- Battery voltage range: 40 – 60 V
- Maximum charging / discharging current: 150 A
- Number of battery inputs: 1
- Designed for efficient and responsive battery operation
Advanced PV Input & MPPT Configuration
- Maximum DC input power: 9,000 W
- MPPT channels: 2
- Maximum DC input voltage: 550 V
- Flexible solar array design for a wide range of installations
High Efficiency & Thermal Management
- Maximum efficiency: 97.6%
- MPPT efficiency: >99%
- Intelligent air cooling for stable long-term operation
- Operating temperature range from -40°C to +60°C (derating above 45°C)
Durable & Installation Ready
- IP65 ingress protection for indoor and outdoor installations
- Engineered for Australian environmental conditions
Downloads
