PowerPlus Escape60 IP21 RECTIFIER 24kW/1Ph or 2Ph - ESCA6024-100-000

Overview

The PowerPlus Escape60 Rectifier is a high-capacity AC-to-DC rectifier solution designed to enable grid-based battery charging for large-scale energy storage systems. Accepting single-phase, split-phase, or three-phase grid power, the Escape60 is most commonly paired with the PowerPlus Escape20 to support a wide range of grid configurations.

When integrated with an Escape20, the system can form a three-phase micro-grid while also supporting direct connection to a three-phase generator. Designed for reliability, flexibility, and serviceability, the Escape60 is ideal for demanding commercial and industrial energy storage applications.

Key Features

Flexible Grid Charging Capability

• Accepts single-phase, split-phase, or three-phase grid inputs
• Supports charging from weak or “harsh” grid conditions
• Input limits can be adjusted to suit site-specific grid constraints

Available Power Configurations

• ESCA6024-100-000 – 24 kW rectifier configuration
• ESCA6036-100-000 – 36 kW rectifier configuration

Optimised for Escape20 Integration

• Typically paired with the PowerPlus Escape20 BESS
• Escape20 provides a three-phase micro-grid output
• Supports direct connection of a three-phase generator

Modular & Serviceable Design

• Rack-mounted rectifiers with modular architecture
• Hot-swappable rectifier modules minimise downtime
• Factory-programmed controller optimised for PowerPlus batteries

Battery System Compatibility

• Supports up to 14 batteries within the Escape60 enclosure
• No additional storage required beyond Escape20 minimum battery count
• 36 kW configuration requires a minimum of 19 batteries in the system
